Description
The slimmed-down throat plate easily adjusts to the sewing of small tubular articles with diameters as small as φ40mm. This enhances the machine’s ability to smoothly sew not only bags and shoes, but also small article such as wallets. The newly developed mode of highly rigid rectangular feed guarantees outstanding feed performance.
- Includes Power Stand for USA: The Cylinder of machine bed sticks off the left hand side of the table giving it open or free arm type advantages.
- Cylinder-bed, single-needle, Unison-feed, Lockstitch Machine with a Vertical-axis Hook
- The LS Series offers a consistent stitching pitch and outstanding ability to sew sharp curves.
This makes the machine ideal for the sewing of tubular articles.* With large vertical-axis hook
* The machine is equipped as standard with a mechanism to correct uneven material feed by making-micro adjustments to the bottom-feed
* Compared with the elliptical feed, the rectangular feed helps reduce gathered stitches
* The ratio of alternate vertical movement remains unchanged even when the material thickness changes
* Higher lift of the presser foot
* The maximum alternating vertical movement is 6.5mm
* Excellent operability and maintainability
* The underside of the top end of the cylinder-bed is provided with an easy-to-remove cover. This promises easy cleaning of thread wastes
* The stitch length can be easily selected by the stitch dial
* The machine’s enhanced operability features include a clear view of the area around the needle, placement of the bobbin thread winder on the front face of the machine arm, and a large handwheel
* A knee-lifter mechanism is built in the bed. This reduces the pressure required to operate the knee-lifter and facilitates setup
* The machine’s full-open-type top design makes adjusting works easier
* The machine comes with a lubricating mechanism that uses a centralized oil wick
* This substantially reduces the time and trouble required for oiling the machine. (The hook needs manual oiling with an oiler)
* A walking foot mechanism is built into the machine arm to prevent oil from scattering
* Complete with table stand and motorThe underside of the top end of the cylinder-bed is provided with an easyt o-
remove cover. This promises easy cleaning of thread wastes.
The stitch length can be easily selected by the stitch dial. The machine’s
enhanced operability features include a clear view of the area around the
needle, placement of the bobbin thread winder on the front face of the
machine arm, and a large handwheel (160mm).
- Thread range: #50-#8, B33-B92, Nm_120/3-30/3
- Distance from needle to neck 255mm
- Cylinder Bed Diameter 72mm
- Motor Output 750W
- Machine Weight 37.5 Kg / 82.6 lbs
