Description
Includes table & Servo Motor.
THIS MACHINE NEED TO BE ASSEMBLE.
APPLICATIONS
- For sewing light and medium weight fabric, leather, vinyl, canvas and various laminated and coated materials
- Designed for stitching articles such as raincoats, underwear, corsets, brassieres and similar products
- Suitable for vamping, space stitching and tipping on shoes
FEATURES
- Vertical axis hook
- Drop feed
- Roller presser foot allows for turning of sharp corners and tight curves
- Single needle
- Stitches per minute – 3000*
- Reverse feed
ADDITIONAL INFORMATION
SPECIFICATIONS
| Number of Needles | 1 (Single) |
| Feeding Mechanism | Drop Feed |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 3000 |
| Clearence Under Presser Foot | 15/64″ (6mm) |
| Stitch Length | 5 s.p.i. (5mm) |
| Needle | DP-F22/134S |
| Bobbin | Pre-Wound G |
| Stitch Type | 301 |
| Needle Bar Stroke | 1 1/4″ (32mm) |
| Hook | 12032 |
| Post Height | 7″ (178mm) |
| Work Surface | 1 7/8″ x 2″ (48mm x 75mm) |
Additional information
| Weight | 3.06 lbs |
|---|---|
| Dimensions | 29.18 × 15.51 × 11.36 in |
